Experimental Module Refrigeration System

Experimental Module Refrigeration System
Experimental Module Refrigeration System
Product Code : CEI122
Brand Name : Chhabra Engineers
Product Description

Experimental Module Refrigeration System

Fundamental principles of refrigeration engineering
- Components of a refrigeration circuit
-  Calculations in a refrigeration circuit:

   energy balance
   coefficient of performance
   compressor power
   refrigerating capacity
   compressor pressure ratio
   volumetric efficiency
- Plotting a p-h state diagram

Technical Description
 The  facilitates fundamental experiments in the area of refrigeration engineering. The unit contains a closed refrigerant circuit with open compressor, a condenser with switchable fan and an evaporator in a refrigeration box with transparent door and an adjustable heat load.

Specification

[1] Experimental module for refrigeration unit
[2] Driven by CEI 122
[3] Open compressor, 2 cylinders, max. refrigerating capacity: 845W, stroke: 26mm, bore: 35mm
[4] Refrigerating chamber with transparent door and adjustable heat load
[5] Lamellar radiator as heat load, 500W
[6] Air-cooled evaporator
[7] Condenser with fan
[8] Electronic sensors with digital displays for measurement of pressure, temperature, flow rate
[9] PC data acquisition , software under Windows XP
[10] CFC-free refrigerant R134a
