Heat Pump With Dual Mode Evaporator

Heat Pump With Dual Mode Evaporator
Heat Pump With Dual Mode Evaporator
Product Code : CEI125
Brand Name : Chhabra Engineers
Product Description

Heat Pump with Dual Mode Evaporator

Energy balance for water and air operation
- Cyclic process on the p-h state diagram
- Effect of cooling water inlet temperatures and oil
  cooler

Technical Description
 This compact benchtop unit comprises components that are commonly used in industrial systems. A special feature of this system is that the evaporator can be operated with either water or air. A hermetic compressor with integrated oil cooler creates the refrigerant flow in the system.
Specification

1] Air-to water heat pump as benchtop unit
[2] Evaporator can be operated with either water or air (plate heat exchanger, finned tube evaporator)
[3] hermetic piston compressor with integrated oil cooler
[4] Coaxial condenser
[5] High/low pressure shut down (pressostats)
[6] Temperature sensors with display and selector switch
[7] CFC-free refrigerant R 134a
[8] l x w x h: 1030x675x702mm, 40kg
[9] 230V, 50/60Hz, 1 phase
Hermetic compressor: power consumption: 420W at -10/32°C, refrigerating capacity: 1140W at -5/32°C
Water-cooled evaporator: 1kW, plate type heat exchanger, max. flow rate: 4m³/h
Air-cooled evaporator: 1kW, finned tube type, max. airflow rate: 290m³/h
Coaxial condenser: 2kW
Measuring ranges:
Pressure: -1...9bar / -1...24bar, power: 0...600W, temperature: -20...200°C, flow rate (water)
